Specifications
*Specifications*
Part Number: 67Y2610-AX
Formatted Capacity: 1TB
Interface SATA: 3.0Gb/s
User sectors per drive: 1,953,525,168
*Performance*
Data transfer rate (max)
Buffer to host: 3.0Gb/s
Host to/from drive (sustained): 128MB/s
Cache (MB): 64
Rotational speed (RPM): 7200
Average drive ready time (sec): 18
*Configuration/Organization*
Heads/disks: 4/2
Bytes per sector (STD): 512
*Reliability/Data Integrity*
Load/unload cycles: 600,000
Non-recoverable read errors per bits read: <1 in 10^15
*Power Management*
12VDC (A, max): 1.6
Average power requirements (W)
Read/Write: 7.9
Idle: 5.9
Standby: 0.7
Sleep: 0.7
*Environmental Specifications*
Temperature (°C)
Operating: 5 to 55
Non-operating: -40 to 70
Shock (Gs)
Operating (2 ms, read/write): 30
Operating (2 ms, read): 65
Non-operating (2 ms): 300
Average acoustics (dBA)
Idle mode: 28
Performance seek mode: 33
Quiet seek mode: 29
As used for storage capacity, one megabyte (MB) = one million bytes, one gigabyte (GB) = one billion bytes, and one terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on operating environment.
Specs based on Western Digital P/N: WD1003FBYX and are subject to change without notification.
