Capacity: 1.6TB
Components: 3D eTLC
Interface: SAS
Transfer Rate Synchronous (Maximum): 12Gbps
Form Factor: 2.5–inch
RoHS Compliant
Bandwidth Performance:
- Sustained Sequential Read: Up to 2200 MB/s
- Sustained Sequential Write: Up to 1550 MB/s
Read and Write IOPS (Full LBA Range, IOMeter Queue Depth 32):
- Random 4KB Reads: Up to 230,000 IOPS
- Random 4KB Writes: Up to 120,000 IOPS
Endurance: 3 drive writes per day for 5 years
- 1.6TB: 8,760 TBW
Operating Temperature: 0° C to 70° C
Maximum altitude: 10,000 ft
Average Power Consumption: Active: Up to 8.5 W (TYP) - Idle: 4.4 W
Power Management: 5.0 V ± 5%
Reliability (MTBF): 2,000,000 Hours
Shock: 1,500 G/0.5 ms
Warranty
5 Year Limited Warranty
